VEN-830-22U3M-M01

1/1.8", 22FPS, 3840×2160, MONO, ROLLING SHUTTER, IMX334, USB3.0

The VEN-830-22U3M camera is a monochrome all-in-one board level camera with the Sony IMX334 CMOS sensor. The VEN-830-22U3M provides four lens mount options: C mount with housing, S mount with housing, CS mount with housing and No mount (bare board).

Thanks to the extremely compact housing and various mount options, the VEN-830-22U3M is more flexible in demanding space.

• USB3.0（Micro B）interface with 10-bit or 8-bit Mono output
• Gain, auto gain, exposure and auto exposure
• Storable user sets
• Support Reverse X/Y (horizontal and vertical mirroring)
• Support hardware trigger and software trigger
• 16KB data storage area for saving algorithm coefficients, parameter configuration, and so on
