MER2-503-36U3M POL

2/3", 36FPS, 2448×2048, MONO, GLOBAL SHUTTER, IMX264, USB3.0

The MER2-503-36U3M POL camera is a polarization camera with the Sony IMX264 MZR CMOS sensor, and capture image of four different light directions simultaneously. Polarization camera can inspect reflective surface such as glass, metal which are difficult for monochrome or color camera.

Thanks to the extremely compact (29mm × 29mm), robust metal housings and locking screw connectors, the MERCURY2 cameras can secure the reliability of cameras deployed in harsh environments. The MER2-503-36U3M POL camera is powered over the USB interface and has opto-isolated I/Os.

The GPIOs give MER2-U3 maximum flexibility to adapt to specific needs.

• Trigger mode: Frame Start /Frame Burst Start
• Two exposure time modes: Standard exposure time mode / UltraShort exposure time mode
• Support Timed exposure mode and TriggerWidth exposure mode
• Decimation, Binning, Digital Shift, Noise Reduction and Black Level
• Adjustable Gamma and Sharpness for optimizing the brightness and sharpness of images
• Programmable LUTs and User Set Control
• Support Timer and Counter
• Support Remove Parameter Limit to expand the range of exposure, gain and so on
• 16KB data storage area for saving algorithm coefficients and parameter configuration
