MER2-503-23GM

2/3", 23.5FPS, 2448×2048, MONO, GLOBAL SHUTTER, IMX264, GigE

The MER2-503-23GM camera is a monochrome GigE Vision camera with the Sony IMX264 CMOS sensor. Thanks to the extremely compact (29mm × 29mm), robust metal housings and locking screw connectors, the MERCURY2 cameras can secure the reliability of cameras deployed in harsh environments.

The MER2-503-23GM camera has opto-isolated I/Os. The GPIOs give cameras maximum flexibility to adapt to specific needs.

• Auto Gain, Auto Exposure, ROI
• Binning, Decimation
• Timer, Counter, LUTs and User Set Control
• Gamma, Black Level, Digital Shift, Sharpness
• Support Noise Reduction
• Remove Parameter Limits
