MER2-302-56U3C

1/1.8", 56FPS, 2048×1536, COLOR, GLOBAL SHUTTER, IMX265, USB3.0

The MER2-302-56U3C camera is a color USB3.0 Vision camera with the Sony IMX265 CMOS sensor. Thanks to the extremely compact (29mm × 29mm), robust metal housings and locking screw connectors, the MERCURY2 cameras can secure the reliability of cameras deployed in harsh environments.

The MER2-302-56U3C camera is powered over the USB3.0 interface.

• Trigger mode: Frame Start /Frame Burst Start
• Two exposure time modes: Standard exposure time mode / UltraShort exposure time mode
• Decimation, Binning, Digital Shift and Black Level
• Adjustable Gamma for optimizing the brightness of images
• Support Light Source Preset, Color Transformation Control and Saturation
• Programmable LUTs and User Set Control
• Support Timer and Counter
• Support Remove Parameter Limit to expand the range of exposure, gain and so on
• 16KB data storage area for saving algorithm coefficients and parameter configuration
